MOBILE INVENTORY READER– LIBASSIST

WIRELESS SEARCH AND INVENTORY

The LibAssist Handheld Reader consists of an RFID reader that communicates via a wireless connection (wifi / usb / bluetooth). The LibAssist software has three main functions: inventory, research and weeding. The inventory reader software controls the RFID reader and analyzes the new tags.

SCAN

In inventory mode, each scanned RFID tag is stored in a list and stored in a file, which can be exported to a Windows® PC with the software that accompanies the LibAssist Handheld Reader.

DESCRIPTION

Physical properties
Dimensions (mm)	340 x 105 x 265 (l x w x h)
Weight	750 g
Material	Polyurethane 8051
Colour	RAL 7015 Grey
Identification	HF RFID Barcodes 2D Coding
Load	Desktop charging station with USB connection

RFID Specifications
The Technology:	RFID
Frequency:	13,56 MHz
Maximum power:	1 W
Battery
– Voltage	7.4 (rechargeable, removable Lithium-ion)
– Capacity	2600 mAh
– Power	300 mAh
– Lifetime per charge	30 hours
– Load	2.5 hours (up to 90%) / 5 hours (up to 100%)

Environmental specifications
Operating temperature:	– 20 / + 55 °C
Storage temperature:	– 20 / + 60 °C
Loading temperature:	+ 0 / + 4 5 °C

avantages

Easy to use
Ergonomic design /light weight
Sound alarm alert
Wide and clear screen
Antenna with position adjustment
Uses all communication standards such as WLAN, GPRS, Bluetooth and USB and Ethernet

RESEARCH

In search mode, a file containing a list of items is exported from the PC and loaded into the LibAssist Handheld Reader. The software scans the RFID reader and searches for an item corresponding to one of the items in the list. When such an item is found, it is marked on the list, and / or an audible alarm sound.

WEEDING

With the wedding function, it is possible to search for books that do not belong to a certain part of the library. In the Inventory Reader, you place a list of books you want to search for in a part of the library. The software scans the reader and RFID searches. When an item is read, it is not on the list and an alarm sound.

USABILITY

The Player is battery-powered and has a past-proof design that is compatible with previous versions. The weight is less than 1 kg. Due to shape and weight, employees are not affected by user experience.
